Reading 90-130cm RFID long range reader with RS232/Wiegand26 / Wiegand34

-
Reading 90-130cm RFID long range reader with RS232/Wiegand26 / Wiegand34
(1)Introduction:

GP99 is an extended range 125kHz RFID Long Range proximity reader featuring compact dimension.It can read range from 90cm to 130 cm depends on the interference on site. GP99 can effectively penetrate solar film and allows MC-5 proximity card to be read from inside the car without winding down windows. The unit will run an excellent power supply and marking it particularly suited to access control,car parking and through-well reading applications.

Ideal solution for car parking access control; residential and commercial building – no more hand getting wet during rainy day and less car robbery risk at entrance.
(2)Features:
Ø   Can penetrate solar film (V-Kool40).
Ø  Auto tuning function to compensate presence of metal and interference.
Ø  Extended reading range from 90 cm to 130 cm.
Ø  Bright LED indicators, tuning LED bar.
Ø  Firmware up gradable in the field..
Ø  IP-54 waterproof housing design.
Ø  High-quality power supply with noise filter included.
Ø  Loop Inductive function optional.
Ø  Anti-rereading function included.

125k long range proximity reader
(3)Application examples:
Ø  Access Control.
Ø  Car Parking Systems.
Ø  Through -wall Reading Application.
Ø  Personal indentification.
Ø  Any Long Range Reading Application.
Ø  Hand Free Applications.

(4)GP99 Advantages
Ø  Anti-Rereading function,
Ø  Anti-Interference,
Ø  Signal LED indicators,
Ø  Loop Inductive function (Selectable),
Ø  IP54 Water-proof level,
Ø  Long Service Life.
*when the card within in the inductive range and card ID be read by one reader, the other reader will not read this card again. This function is main be used  for solve the interference problems behind the other reader.
*Under the same environment, GP99 anti-interference ability is strong, very afflictive external conditions.
*Our reader with the IP54 water-proof level, and it can work perfectly in the rainy days, no need the additional accessories, and it can save your cost ,and customers pay less money but can got very good experience.
*Our reader has integrate the loop inductive function, it can work with our vehicle loop detector. For some special application, you can connect to the loop detector and when the vehicle on loops, the card can start to work with the reader, which can make the whole system with high reliable and stable.
(5) Package list
1 pcs GP99 reader
1 pcs power supply
2 pcs EM card
gP99 READER PACKAGE
